TECHNICAL SPECIFICATION
Stand : Stand and Robust, traditional horse shoe base.
Packing : Thermocol, cardboard box and dust cover.
(Wooden box with lock and key is available on extra charge.)
Body : Monocular die-cast body, inclinable up to a horizontal position (90°).
Magnification : 100X ~ 600X
Stage : Plain square stage of 125 X 125 mm, with two clips.
Nosepiece : Triple hole nosepiece with positive click stops for precise and smooth alignment of objectives.
Focusing : By coarse & fine focusing knobs.
Eyepieces : Hygienical 10x and 15x.
Objectives : Two achromatic objective of 10x and 45x.
Condenser : Built-in Substage Condenser with iris diaphragm.
Illumination : Plano-concave mirror in adjustable fork mount.
Colour : Grey or black
