Stand : Stable & Robust, traditional Horse Shoe base body. Body inclinable through 90 degree, Standard tube length of 160 mm
Focusing : Separate coarse and fine focusing knobs with graduation on one side. Coarse movement by Rack & Pinion and Fine movement by Screw Lever Mechanism
Nosepiece : Quadruple Revolving Nosepiece is provided with positive click stop for proper centering
Stage : Fixed Stage size 125X125mm with detachable mechanical stage for X and movement of slide up to 25 X 75mm with graduated scales and verniers
Illumination : illumination through a 50mm diameter plano concave mirror mounted o gimbal mount
Objectives : Three Achromatic Objectives : 10 X 45 X (SL) & 100 X (SL) Oil immersion
Eyepieces : Two Huygenian Eyepieces : 5X & 10 X
Condensor : Sub Stage Abbe condenser with N.A. 1.25 moves up and down by rack & pinion. Iris diapharagm and filter holder are mounted with the condenser
Safety Device : Adjustable down movement stopper for preventing accidental damage.
Packing : Thermocol, cardboard box and dust cover.
(Wooden box with lock and key is available on extra charge.)
