INCLINED MICROSCOPECat No: HR-3154

TECHNICAL SPECIFICATION :
Frame                           All aluminium pressure diecasted body.
Paint                             Powder coating available various desired shades
Nose piece                   Quadruple ball bearing nosepiece
Observation head         360° rotateable and 45° inclined head with allantois fungus coated prisms.
Focusing system          Separate knobs for cores and fine motion having least count of 0.02mm
Mechanical stage         CXL mechanical stage works on dovetail slides. (other stage also available)
Condenser                   Bright field sub stage condenser having 1.2N.A.
Eyepieces & objective  Set of 4x, 10x 40x and 100x and a paired set of 10x wide field eyepieces.
Illumination    6V/20W halogen lamp need 220V and 50Hz supply
