  • BINOCULAR CO-AXIAL MICROSCOPE1

BINOCULAR CO-AXIAL MICROSCOPECat No: HR-3152

Body                          :     Inclined Binocular Body, Rotatable through 360 degree.
Nose Piece                :     Perfectly centered bearing based, Quadruple resolving nose piece.
Observation Head     :      360 degree rotatable and 45 degree inclined head anti-fungus coated prisms.
Mechanical Stage      :     Large stable base (120x 125mm) fitted with co-axial precision graduated mechanical stage for X and Y movement of slide upto 50mm x 75mm
Sub Stage                  :    Abbe N.A.1.25 condenser, focusable with rack and pinion through 25mm continuously visible iris diaphragm with built in swing out filter holder.
Anti Fungus Eye Pieces    :     Highest quality paired Huy.5x and WF 10x Eye Piece.
Focusing                   :     Single Co-axial knob provided based on a four step gear reduction system for coarse and fine focussing for silk smooth operation.
Illumination               :     Fitted with built in base halogen light source; fitted with led 3w light; On / Off Switch and light intensity regulator; complete with power cord and plug.
Frame                      :     All aluminum pressure dissected body
Paint                        :     P.U. coating in light cream shade
Packing                   :     Thermocol and cardboard box and dust cover.
                                      (Wooden box with lock and key is available on extra charge.)
